Rotary Table Sorter

The new "non solid" ring design allows both the inner and outer rings to be dropped, realizing more openings and smaller floor area,The number of chutes is more ,smaller footprint and better site adaptability; At the same time, the modular design is adopted, which can flexibly adapt to various site and grid requirements by changing the diameter. It is applicable to nodes such as district and county level, key delivery departments, and has a high rate of return on investment.

Product Important Indicators and Functions

Diameter 6 meters size, the number of compartments is 23

Single level

Sorting efficiency：

approximately 4000 pieces/hour

Mail weight：

0.01-15kg

Mail size：

minimum 100mm×100mm×1mm；
Maximum00mm×400mm×400mm

Number of chutes：

20-100个（customizable）

Floor area：

6m diameter model, with a net floor area of approximately 30 square meters

Three indicators

Sorting efficiency：

approximately 4000 pieces/hour

Mail weight：

0.01-15kg

Maximum mail size：

500mm×400mm×400mm

Slide to see more

Single level

Three indicators

Application Scenario

Adopting modular design, it can flexibly adapt to various site and grid requirements by changing the diameter, and is suitable for nodes such as district/county level and key delivery departments, with high investment return rate.
